Timer Switch

Timer Switch

AH711, AH710

Technical Data

AH711, AH710
AH711, AH710
Classification Timer
Model AH711 AH710
Contact Capacity AC220V 16A
Full Timing Range 24h
Contact Resistance ≤50mΩ
Insulation Resistance ≥100mΩ
Coil Voltage 230V AC
Electrical 105times
Mechanical 107times
Operating Temperature -10℃~+55℃
Storage Battery(Working Reserve) 70h Without Battery
Min. Setting Unit 10 Minutes
Set Up Times 10m/per times 144times
Remarks --


AH711, AH710
